AY自吸热油泵应用范围、结构特点外形及安装尺寸

AY型离心油泵性能参数表

型号性能参数	流量	扬程 (m)	转速	效率 %	汽蚀余量 NPSH m	轴功率	配带电机
型号性能参数	流量	扬程 (m)	转速	效率 %	汽蚀余量 NPSH m	轴功率	型号	功率(kw)
40AY40×2	6.25	80	2950	30	2.7	4.5	YB132S₂-2	7.5
40AY40×2A	5.85	70	2950	30	2.6	3.7	YB132S₁-2	5.5
40AY40×2B	5.4	60	2950	30	2.5	2.9	YB112M-2	4
40AY40×2C	4.9	50	2950	30	2.5	2.2	YB100L-2	3
50AY60	12.5	67	2950	42	2.9	5.4	YB132S₂-2	7.5
50AY60A	11	53	2950	30	2.8	4.1	YB132S₁-2	5.5
50AY60B	10	40	2950	37	2.8	2.9	YB112M-2	4
50AY60×2	12.5	120	2950	35	2.4	11.7	YB160L-2	18.5
50AY60×2A	12	105	2950	35	2.3	9.8	YB160M₂-2	15
50AY60×2B	11.5	89	2950	33	2.2	8.4	YB160M₁-2	11
50AY60×2C	11	78	2950	33	2.2	7.1	YB160M₁-2	11
65AY60	25	60	2950	52	3	7.9	YB160M₁-2	11
65AY60A	22.5	49	2950	51	3	5.9	YB132S₂-2	7.5
65AY60B	20	38	2950	49	2.7	4.2	YB132S₁-2	5.5
65AY100	25	110	2950	47	3.2	15.9	YB180M-2	22
65AY100A	23	92	2950	46	3.1	12.5	YB160L-2	18.5
65AY100B	21	73	2950	45	3	9.3	YB160M₂-2	15
65AY100×2	25	200	2950	47	2.8	29	YB200L₂-2	37
65AY100×2A	23	180	2950	46	2.8	24.5	YB200L₂-2	37
65AY100×2B	21.5	155	2950	45	2.7	20.2	YB200L₁-2	30
65AY100×2C	19.5	130	2950	44	2.7	15.7	YB180M-2	22
80AY60	50	60	2950	62	3.2	13.2	YB160L-2	18.5
80AY60A	45	49	2950	61	3.2	9.8	YB160M₂-2	15
80AY60B	40	39	2950	60	3.1	7.1	YB160M₁-2	11
80AY100	50	100	2950	56	3.1	24.3	YB200L₂-2	37
80AY100A	45	85	2950	55	3.1	18.9	YB200L₁-2	30
80AY100B	41	73	2950	54	2.9	15.1	YB180M-2	22
80AY100×2	50	200	2950	57	3.6	47.8	YB280S-2	75
80AY100×2A	46	175	2950	55	3.5	39.9	YB250M-2	55
80AY100×2B	43	150	2950	54	3.3	32.5	YB225M-2	45
80AY100×2C	40	125	2950	52	3.3	16.2	YB200L₂-2	37
100AY60	100	60	2950	70	4.1	12.3	YB200L₁-2	30
100AY60A	90	49	2950	64	4.5	18.8	YB200L₁-2	30
100AY60B	79	38	2950	65	3.5	26.2	YB160L-2	18.5
100AY120	100	120	2950	63	4.3	23.3	YB280S-2	75
100AY120A	93	105	2950	61	4	43.6	YB250M-2	55
100AY120B	85	88	2950	59	3.8	34.5	YB225M-2	45
100AY120C	78	75	2950	56	3.6	28.5	YB200L₂-2	37
